Split plummer block housings, SNL 30, 31 and 32 series
SNL plummer (pillow) block housings in the 30, 31 and 32 series are robust and suitable for tough operating conditions. They enable the incorporated bearings to achieve maximum service life with less need for maintenance. Different housing variants and seal designs are available, making the use of tailored housings virtually unnecessary and enabling cost-effective bearing arrangements to be made.
Bearing types
Spherical roller bearings
CARB toroidal roller bearings
Bearing dimension series
30, 31, 32
22, 23, 40 (for some bearings)
Shaft diameter range
115 to 530 mm
4 7/16 to 19 1/2 in.
Typical shaft-bearing combinations
Plain shaft with bearing on an adapter sleeve
Stepped shaft with bearing on a cylindrical seat
Seals
Labyrinth
Heavy-duty
Oil seal
Lubrication
Grease
Oil
Materials
Grey cast iron
Spheroidal graphite cast iron
Mounting
Four-bolt mounting
Compliance to standards
ISO 113:2010 (four-bolt plummer block housings)
Supersedes
SD, SDD series
