Agricultural Bearing

Agricultural Bearing

By providing innovative solutions, Singapore Bearing Industrial services will meet all of your requirements and simplify the management of your agricultural equipment.


Singapore Bearing Industrial services will continue efforts to further meet customer needs with bearings and bearing products using cutting-edge technologies.





Bearing Technology Advantage

Increased service life
Singapore Bearing Industrial services have been designed to meet the requirements of agricultural equipment: higher speeds on the road, an increase in transmitted power, reduced size (downsizing)
Increased machine performance
Singapore Bearing Industrial services are designed for all types of environments and all types of machine. Improve the performance of your equipment by using products that have been specially designed for each application.
Lower maintenance costs
Singapore Bearing Industrial services are developed to withstand harsh environments. They ensure greater robustness and reliability. No downtime during periods of intensive work.
Bearings designed for tractor transmissions
In addition to a wide range of products available in our catalogue, our engineers have developed products that are designed to meet the specific needs of the different functions found in tractor transmissions and axles:
drive pinion: steep angle tapered roller bearings with reduced friction torque to allow an increase in rotational speed.
wheel bearing – rear axles: tapered roller bearings with an optimised internal design to limit edge loads induced by axle shaft deflections and heavy applied loads.
wheel bearing – front axles: thin section angular contact ball bearings for increased rigidity in confined spaces.
gearbox: high performance deep groove ball bearings TMB/TAB for increased service life or reduced size (downsizing) with the same useful life as that of a larger bearing.
final reduction planetary gears: large choice of versions of cage and needle roller assemblies suitable for all dimensions and power to be transmitted.
Bearings designed for towed agricultural machinery
At Singapore Bearing Industrial , bearings for towed agricultural machinery form a range of products designed for the specific requirements of each type of machine: disc harrows, rotary harrows, seeders, mowers, balers…
The most used bearings in towed machines are traditionally self-aligning bearings inserts, in sheet metal or cast iron housings, and deep groove ball bearings.
Tillage
support for packer rolls / roll bar support: ball bearing inserts with triple lip seals + deflector shield (``AGR” suffix). This highly reliable solution is approved by the leaders in the field of rotary and disc harrows.
independent disc harrows: tailor-made integrated hubs provide you with high performance without the need for maintenance.
Seeding
seed drill disc: 4 point contact ball bearing with triple lip seals, a guarantee of precision sowing and long service life.
Sillage making
disc mower cutting bar: double row angular contact GB ``Twinline” ball bearing. The world leader in haymaking equipment has used this type of bearing for more than 30 years due to its high speed capability, ease of mounting and in particular for its extreme reliability.
Baling
baler: ball bearing insert equipped with an ``L4`` labyrinth seal which offers the best compromise between speed capability and resistance to liquid and solid contamination.



Increased service life

Lower maintenance costs

Increased machine performance

  • Bearings for Machine Tools
  • Bearing unit
  • Ball bearings

Bearing unit is a combination of a radial ball bearing, seal, and a housing of high-grade cast iron or pressed steel, which comes in various shapes. The outer surface of the bearing and the internal surface of the housing are spherical, so that the unit is self-aligning. The inside construction of the ball bearing for the unit is such that steel balls and retainers of the same type as in series 62 and 63 of the deep groove ball bearing are used. A duplex seal consisting of a combination of an oil-proof synthetic rubber seal and a slinger is provided on both sides.
